General Specifications(詳細說明)：
Winding Type………………………………………………… Star
Temperature Rise…………………………………………120℃ electrical angle
Insulation Class…………………………………………B
Ambient Temperature Range…………………………-20℃~+50℃
Insulation Resistance………………………100MΩMin.500VC DC
Dielectric Strength………………………………700V AC 1 minute
Electrical Specifications(技術數據): 型號Model | 86BL70-240 | 86BL100-440 | 86BL125-440 | 86BL125-640 | 極數Number of Poles | 8 | 相數Number of Phases | 3 | 額定電壓 Nominal voltage VDC | 24 | 48 | 48 | 310 | 額定轉速 Rated speed RPM | 3000 | 額定扭矩 Rated Torque N-m | 0.8 | 1.6 | 2.4 | 2.4 | 額定電流 RatedCurrent Amps | 14 | 14 | 21 | 3.3 | 輸出功率 OutputPower Watts | 250 | 500 | 750 | 750 | 峰值扭矩Peak Tourque N-m | 2.4 | 4.8 | 7.2 | 7.2 | 峰值電流Peak Current Amps | 42 | 42 | 63 | 10 | 力矩常數Torqueconstant N-m/A | 0.06 | 0.115 | 0.115 | 0.73 | 反電勢常數 BackEMF V/kRPM | 4.2 | 8.2 | 8.2 | 55 | 轉動慣量 Rotor inertia Kg·cm2 | 0.8 | 1.6 | 2.4 | 2.4 | 電機長度Body Length (L) mm | 98 | 125 | 152 | 152 | 重量 Mass kg | 1.85 | 2.6 | 4.0 | 4.0 |
警戒:峰值力矩僅作為參數參考,接近或在此條件下長期使用,將導致電機損壞Caution 1: Peak (Stall) Torque is provided for the purpose of performance calculations only. Operate near, or at, a stalled condition will result in motor damaged. 注意:以上僅為代表產品,電壓，功率、轉速可根據客戶要求制作Note: We can also manufacture products according to customer's requirements.
|
